The Bridge Edition
A Primer on Bridges
Author: Jake and Stake
Bridges are smart contracts that intermediate the flow of assets to and from different blockchains. In essence, they connect two chains together. These chains can be different Layer 1s (L1s)—like connecting Ethereum to Bitcoin, L1-L2 connections—Ethereum to Arbitrum, or L2-L2 connections—Optimism to zkSync.
Remember that blockchains are like closed systems. They have different rules and communication protocols that make it difficult for them to exchange information—and value—with each other. However, bridges offer a solution. They connect blockchains together and serve as a canal between different liquidity sources.
Bridges allow users to try features on different ecosystems without having to buy additional assets or use fiat exchanges as an intermediary.
Cross-chain Bridges
When you want to move an asset from one chain to another, L1 to L1, you have to use bridges to facilitate the migration. For example, suppose you want to move an asset X from chain A to chain B. First you’d deposit X in the bridge contract on A.
X → A bridge
This contract would communicate to a bridge contract on chain B and issue a derivative representing that deposited asset X, denoted as X’.
X → A bridge → B Bridge → X’
You can then trade, swap, or earn yield on X’ however you’d like, and this asset should always be backed by X on chain A.
The process is similar if a user wants to exchange their X’ on B for X on A.
X’ → B bridge → A Bridge → X
Some examples include the Polygon sidechain bridge and WBTC.
Note that cross-chain bridges require some kind of intermediary or trusted party to perform the exchange. Bridged L1 assets can only be verified by the respective protocol’s permissioned node operators. Often this is the most risky bridge (all things equal) because you have to trust:
The security of the L1 protocol
The integrity/competence of the bridge operators
The security of the second L1 protocol
L1-L2 Bridges
We’ll be focused on bridges to Optimistic Rollups, but ZK Rollups function in a similar manner. ZK solutions aren’t fully EVM equivalent yet, and they don’t necessitate a waiting period for withdrawals, bridging back to the L1.
Short introduction to Optimistic Rollups
Optimistic rollups move state storage and computation off-chain and instead write small pieces of data on-chain. These little commitments are made up of compressed transaction data (called fraud proofs) to verify transaction validity.
This replaces the cost of many individual transactions with that of a single transaction: publishing the fraud proof. As a result, the variable cost becomes a fixed cost.
Optimistic rollups are “optimistic” that the transactions are valid, unless challenged by a verifier, as a result, withdrawal transactions can take up to 14 days to be finalized.
Mighty Morphin’ Asset Time
Similar to bridges between different L1s, users can deposit their assets into a bridge on Ethereum which relays information to the rollup where a corresponding amount of assets is minted.
X → L1 Bridge Contract → X’
Assets are deposited into the L2 contract and new assets are minted on the L2. Users can deposit their assets into the bridge contract or deposit their assets into the L2 contract directly.
[This] is a smart contract on-chain, which only has two tasks: processing deposits and withdrawals, and verifying proofs that everything happening off-chain is following the rules. - Vitalik (An Incomplete Guide to Rollups)
This is the most censorship-resistant method.
User transactions are compressed into “batches”. Transactions with inputs to the contract are considered deposits, those with outputs back to L1 are considered withdrawals.
Sequencers (L2 transaction processors/batch creators) are required to publish these transactions as a part of their batch, otherwise their batch will be considered incorrect. You can think of these kinds of transactions as emergency exits (and entrances).
There are other varieties of bespoke bridges that accept assets and mint their own derivatives on the L2, however not all of these derivative assets should be considered “canonical”.
Rollups inherit the security of the L1 they’re scaling, so they unavoidably have the same liabilities. So the main risk here is that the rollup contract becomes compromised. The risk is substantially lower compared to L1-L1 bridges.
Cross-L2 Bridges
These bridges help different L2 ecosystems connect assets with each other.
L2-L2 bridges have similar liquidity problems as L1-L1 bridges. The difference here is that they share the L1 as a path for asset migration. This can extend settlement times and increase costs as multiple transactions must be made to move assets.
The benefits of L2 bridges are
You only need to trust a single L2 at a time
Assets are secured by a single L1
Liquidity-based bridges
Usually, when assets are deposited on bridges a synthetic asset is minted and transferred to the specified address. However, projects like Hop already have a pool of assets on L1 and a pool of synthetic versions on L2. This allows them to quickly transfer tokens as soon as they’re received.
This is especially useful for quickly bridging to and from optimistic rollups which have challenge periods for transaction settlement.
LPs can deposit assets into the bridge and earn fees on their assets. In exchange for this service, bridge users receive faster settlement times, avoiding the challenge period for receiving their assets. Note that LPs take on some risks associated with fraudulent transactions and earn fees in compensation.
Trust Assumptions
Trustful Bridges
In this case, the bridge holding customer funds is controlled by an entity or set of actors. This could be via smart contracts, a multi-sig, or an entirely off-chain system. This is the most centralized version of bridges.
This can allow the bridge controllers to quickly make updates and improvements, but when users put their funds into these bridges, they’re trusting that the entities that control them are benevolent and operationally secure—a dangerous proposition in crypto. Depending on how derivative assets are issued, the bridge can censor or seize your funds, WBTC’s bridge for instance.
There have been several cases of bridges losing customer funds due to key mismanagement.
Trustless Bridges
Trustless bridges operate using only smart contracts—there are no key holders. In this case, the security of the bridge depends on the security of the blockchain and the particular smart contract. While this greatly reduces the attack surface, bridges are still liable to smart contract risk.
The security of a derivative asset is based on the security of the bridge. This means that both the blockchain and the bridge have to be secure. Many of the largest hacks involved bridges.
Stay safe out there!
Bridging Bitcoin and Ethereum
Author: Austin Foss
Amidst the tension between the Bitcoin & Ethereum communities there has been enough motivation in the overlap in users of both chains to build bridges between the two.
Bitcoin on Ethereum
In April 2020, The Defiant published an article on the various "...Bitcoin-on-Ethereum Efforts..." taking place at the time. On a scale from less to more decentralized they ranked six solutions:
wBTC
First on the list wBTC with by far the largest market cap today at more than 180,000 minted according to CoinGecko. Announced in 2018 by its founding company BitGo, wBTC quickly became the go-to way to use BTC in DeFi, having integrations with infrastructure like MakerDAO's vaults drove rapid adoption.
Trust in the security of wBTC over other bridges is based on trustworthiness of BitGo who are currently the only custodian—the role that "[m]inting will only be possible" to be performed by. This centralized security in BitGo is what maintains the 1:1 peg of BTC to wBTC.
As an example of centralization being used for good, Coinelegraph reported that BitGo had refused to redeem 3,000 wBTC for Alameda. While creditors in Alameda's bankruptcy case would likely be happy to hear that a few million worth of assets was safe, just a drop in the bucket out of billions, this kind of centralized interference goes against a core founding principle of crypto; trustlessness.
renBTC
On the decentralized half of The Defiant's scale and the largest of the three in market cap is renBTC, currently at just above 700 minted on chain according to CoinGecko; but that is likely to rapidly decline. Unfortunately for the bridge protocol, "Alameda acquired Ren" in 2021.
This is a pretty big loss for DeFi as the Ren bridge acted as a decentralized option to BitGo's centralized bridge. Ren 2.0 was announced prior to the FTX collapse, but if or when it launches is unknown. Compared to wBTC, renBTC minted on Ethereum never got close to 100,000 tokens but peaked at 20,000.
Hopefully it would take its decentralization a step further because, as 1.0 currently operates:
At the moment, consensus and execution in RenVM is the responsibility of Darknodes that are operated by the Ren core development team, and peer-to-peer networking is the responsibility of Darknodes that are operated by the community. - Ren Community
tBTCv1
Launched in September of 2020, after one previous attempt in May, BTC was bridged to Ethereum in the form of tBTC. In its first year of life, supply peaked at over 1,500 being minted using its bridge.
The product was originally designed as a decentralized application using an intermediary network of nodes called the Keep Network. This decentralized network bridges the Bitcoin and Ethereum chains using "Keep's random beacon, and threshold signatures."
It was designed such that node operator's had to stake KEEP tokens in order to operate a random beacon node, but also stake an amount of ETH to collateralize the tBTC they would mint; minted supply would be maintained 1:1 but also insured by ETH. What made the tBTC bridge the most decentralized on The Defiant's scale is the random selection of node operators for deposits and redemption.
When a user wants to bridge their BTC to Ethereum they send a deposit request and a BTC deposit address is generated for the user from the random beacon nodes, selecting three signers at random from the pool of ETH stakers. Then the user deposits their BTC to that address and a corresponding amount of tBTC is minted for them on Ethereum.
To redeem tBTC for BTC on Bitcoin a similar process would happen in reverse. If a node operator missbehaved or failed to perform the 3-of-3 ECDSA signature they would be slashed.
Network Merger
In all this, where does Threshold Network come in? Throughout 2021 discussions were being held between Keep and another team called NuCypher, resulting in the merger of the two networks in early 2022.
Keep Network
Keep began as a project developed by a company called Thesis founded by CEO Matt Luongo. Thesis has several other projects spread throughout the crypto ecosystem including the Bitcoin focused Fold App, a web3 wallet called Tally, and an Ethereum AMM aimed at stable coins in a similar way to Curve.
When introduced by Zooko on the ZCash forums in 2019 he listed several contributions by Keep to the broader ecosystem including EIPs 159 and 1108, and ZIP-221. This shows a commitment to projects focused on trustlessness, self custody, and privacy across several L1 chains; not much of a stretch to make the primary project of Keep an L1 bridge.
Two of Keep Network's backing partners include Polychain and Andreesen Horowitz. Messari shows the KEEP distribution as follows:
Private sale: 35%
Early team: 10%
Advisors: 5%
Keep SEZC: 25%
Staking & Protocol Incentives: 25%
NuCypher
NuCypher's big project is a tool called Proxy Re-Encryption (PRE). This is a tool enabling distributed access control to encrypted data without ever having to entrust the unencrypted data to a centralized party.
NuCypher's design for PRE closely resembled Keep's method for bridging. Nodes stake NU and perform the encryption service in a distributed way.
In October 2019, Coindesk reported that NuCypher had raised a 10.7 million USD round of funding for 8% of the token supply, and reminded readers that 31% had previously been sold for 4.4 million in 2017. A year after the second round, in September 2020, a further 125 million USD worth of ETH was staked in exchange for NU tokens. NuCypher is also backed by Polychain.
Threshold Network
After the merge both the KEEP and NU token functionalities were replaced by Threshold's T ERC20 token on Ethereum. Both Keep's Random Beacon and tBTC, as well as NuCypher's PRE, are all performed by nodes that have staked 40,0000 T and earn rewards for doing so.
None of these three projects are their own blockchains. Their native tokens all exist on Ethereum, and the nodes that have staked balances perform distributed cryptographic services in a trustless way. Now just under the Threshold name but the other two will still appear in documentation frequently.
When Threshold launched the T token had the following issuance:
10B initial supply
4.5B allocated to NU holders
4.5B allocated to KEEP holders
1B allocated to Threshold DAO
tBTCv2
A revision of the tBTC design was necessary for the project to scale. Due to the tBTC supply needing to be over collateralized by ETH it put a cap on the supply of tBTC as it could only ever be a percentage of the value node operators had to stake in ETH.
Version two of tBTC makes four major changes. Formerly in tBTCv1:
3-of-3 requirement for node signatures
1 address generated per deposit
Node operators needed to stake KEEP and ETH
Fraud, hacks, or other system failures covered by ETH stake
Now in tBTCv2:
51-100 node signatures
One deposit Bitcoin wallet generated about once per week
Node operators just stake 40,000 T
A 'Coverage Pool' now insures the tBTC supply; funds are provided by a separate group of 'underwriters'
Coverage Pools
Coverage Pools were introduced in May 2021 as a tool to increase the supply cap of tBTC, limited by staked ETH. Coverage pools would allow the project to scale to the supply tBTC much further by allowing collateralization with more assets than just ETH.
This of course could be expanded in the future to more coverage pools like, such as having a covETH option, covDAI maybe. Bearing a resemblance to MakerDAO's shift to multi-colateral DAI from a solely ETH back sing-collateral DAI.
For now there exists just one KEEP only coverage pool where depositors are returned covKEEP, redeemable for their original deposits and rewards paid from protocol fees. In November of this year a proposal was made to start a Coverage Pool Migration from a KEEP to a T only pool. According to Matt this hopefully might be "live before optimistic minting".
Optimistic Minting
Optimistic Minting is an updated stop in the tBTCv2 roadmap, added in response to the FTX and Alameda impact on renBTC and "the need for truly decentralized infrastructure" the team is "accelerating the launch of tBTC minting as much as possible while preserving safety... expected to be live by the end of January."
While permissionless minting is still the goal of the project, what this means is that the initial phase of minting tBTCv2 will be handled by two parties named "Minters" and "Guardians".
Minters:
Permissioned group of three to seven participants.
Requests to mint tBTC on each valid deposit.
Three hour delay before mint confirmed.
Guardians:
Permissioned group "from the Threshold DAO and broader DeFi community."
Can cancel an invalid transaction within the three hour delay.
When permissionless minting will be implemented hasn't yet been given a hard deadline.
Security Scares: Performing a Quick Bridge Assessment
Author: d0wnlore
Bridges are used to transfer tokens across different blockchains and have become an invaluable staple for moving value across our ecosystem. They add interoperability between these disparate networks, increasing the velocity of transactions and ultimately making a better user experience for everyone.
Some blockchains have this bridging mechanism built into the system architecture, such as those created with the Cosmos SDK or blockchains in the Binance ecosystem when BNB is transferred. Those that don’t, such as rollups in the Ethereum ecosystem, use smart contracts that take and burn tokens received from users on one blockchain, then mint and send derivatives of the same token on another blockchain through a sister smart contract. Some bridges may skip this burning and minting mechanism, instead keeping tokens in the smart contract as collateral to be used for later transfers.
But bridges share the same risks as any other piece of software, with many in the past falling to vulnerabilities and operational security mishaps that have been known about for a long time. Native bridges may have more flexibility in defining their functionality compared to smart contract bridges, but this can also introduce complexities that make it harder for developers to write their bridge securely. Smart contract bridges will face the same bugs that can plague any other protocol, such as what address is ultimately tied to ownership of a bridge smart contract and how susceptible is that address to being compromised?
Here we will highlight some of the red flags that users should look out for that may indicate that the developers of a bridge may be taking the old mantra of “move fast and break things” too literally. Depending on how a smart contract handles the tokens it receives and sends, a hacked bridge may cause subsequent troubles for the users that have tokens from that bridge.
Before we do that, let’s highlight some of the bridges that have been compromised in the past, which occurred due to a mix of traditional software vulnerabilities or improper key management.
1. Has the bridge been checked for bugs?
Check to see if your desired bridge has been audited and that the developers have provided a complete report to view, not just a summary of findings discovered. Even if the actual content of the report may seem incomprehensible, it acts as a vote of confidence that the developers have engaged with the security community to assess their bridge and made the results public.
If a bridge has been audited take a brief look at the audit report summary to see if the developers have taken the findings to heart. In particular look for any vulnerabilities that have not been addressed by the developers. Are they ignoring low severity issues like gas optimization, making transactions more costly, but do not have a security impact? Or are they ignoring issues that make dangerous assumptions about how the smart contract will be interacted with, which may also be marked as a high severity issue by the auditor but was otherwise dismissed by the developer?
2. Do the bridge owners take security and risks seriously?
It’s a bad sign if a bridge does not have a rich page identifying known risks with using their bridge and how they mitigate those risks. It’s one thing to not show an audit report, but not acknowledging and making users aware of the inherent risks involved with using a smart contract, or other software built upon blockchain technology, may signal that they take the importance of securely transferring tokens too lightly.
It’s one thing for a protocol to tweet or message about how important security is to them. But if those words are not backed up by actual, detailed content, explaining how they take security seriously, then all that marketing just serves as a signal that the protocol does not find security important at all.
3. Is the bridge the team's main focus?
Arguably a bridge that is the main focus of a development team means that the bridge will have more attention devoted to it, which can translate to more resources spent to secure it. The same may not be said for a bridge that is just another project for them, perhaps one that’s just used in a supporting role for the development team’s main project such as another protocol or token.
Most bridges that were compromised in the past were these types of support projects that were not as important as their owners main project, likely resulting in lower standards in keeping those bridges secure.
